EE072
$999.00
The EE072, distributed by Instromart, combines accurate digital measurement, rugged construction, and flexible communication for dependable performance across industries. It’s the ideal choice for applications requiring reliable, long-term humidity and temperature monitoring under tough environmental conditions.
Contact Our Technical Experts 1300 000 000
Get expert advice—select with certainty.
EE072 – Industrial Humidity and Temperature Probe with Digital Output
The EE072, offered by Instromart, is a digital humidity and temperature sensor designed for precise monitoring in industrial, agricultural, and environmental control systems. With Modbus RTU or CANopen output, this probe ensures seamless communication with automation platforms. Built for reliability, it combines a robust IP65-rated housing, fast response time, and sensor coating protection to perform reliably in dusty, humid, or corrosive conditions.
Specifications
| Measured Parameters | Relative Humidity, Temperature, Dew Point, Frost Point, Absolute Humidity. |
| Humidity Range | 0 to 100 % RH (non-condensing) |
| Humidity Accuracy | ±(1.3 + 0.3 % RH) (≤90 % RH); ±2.3 % RH (>90 % RH) |
| Temperature Range | -40 to +80 °C |
| Temperature Accuracy | ±0.1 °C at 20 °C |
| Output Interface | RS485 (Modbus RTU) or CANopen |
| Resolution | 0.01 % RH / 0.01 °C |
| Supply Voltage | 10–28 V DC |
| Power Consumption | Max. 14 mA |
| Protection Class | IP65 |
| Digital interface | RS485 (EE072 = 1 unit load) |
| Response Time (Humidity) | ≤15 s (with stainless steel grid filter) |
| Housing Material | Polycarbonate or Stainless Steel. |
| Connector Type | M12x1 (4-pin) |
| Configuration Tool | PCS10 Software with USB Adapter. |
Main Features
- High-accuracy sensor for simultaneous humidity and temperature monitoring.
- Supports Modbus RTU (RS485) or CAN open for easy system integration.
- Offers additional calculated values: dew point, frost point, absolute humidity.
- Protective sensor coating shields against corrosion, dust, and chemicals.
- Available in stainless steel or polycarbonate housing with IP65 rating.
- Easy configuration and setup via PCS10 software.
- Compact, field-replaceable probe with M12x1 connector.
- Fast response time and excellent long-term stability.
- Enclosure rating: IP65 for demanding industrial and outdoor use 🔹 Humidity range: 0 to 100 % RH
- Humidity accuracy:
• ±(1.3 + 0.3 % of measured value) % RH for ≤90 % RH
• ±2.3 % RH for >90 % RH - Temperature range: -40 to +80 °C
- Temperature accuracy: ±0.1 °C at 20 °C
- Output signal: Modbus RTU (RS485) or CAN open (via M12 connector)
- Resolution: 0.01 °C / 0.01 % RH
- Supply voltage: 10–28 V DC
- Response time (t90): ≤15 seconds with stainless steel grid filter.
- Housing material: Polycarbonate or stainless steel.
Industrial Applications
- Agricultural and livestock climate control systems.
- Food processing and cold storage monitoring.
- HVAC and building automation requiring precise humidity control.
- Cleanrooms and pharmaceutical manufacturing.
- Outdoor weather stations and climate regulation systems.
- Artificial snow production and ski facility monitoring.
