EC-770SE Coating Tester
$999.00
EC-770SE coating thickness gauge measures non-magnetic coatings on steel and insulating coatings on non-ferrous metals.
Contact Our Technical Experts 1300 000 000
Get expert advice—select with certainty.
EC-770SE: High Accuracy Coating Thickness Tester
EC-770SE coating thickness gauge measures non-magnetic coatings on steel and insulating coatings on non-ferrous metals—quickly, accurately, and non-destructively. Look at EC-770XE
Specifications
| Measuring Principle | Fe: Magnetic Induction, NFe: Eddy Currents |
| Measuring Range | 0–2000 μm |
| Accuracy | ±(2% + 1 μm) |
| Resolution | 0.1 μm (0–99.9 μm), 1 μm (≥100 μm) |
| Power Supply | Two 1.5V AAA Batteries |
| Readings Memory | 2000 readings |
| Unit | μm, mm, mils |
| Size / Weight / Case Material | 114 mm x 53 mm x 25 mm / 80 g / ABS |
| Standards / Certificates | CE, ROHS, ISO 2178, 2360, GB / T 4956-2003, 4957-2003 |
| Storage Environment | Temperature: -20–60°C |
| Operation Environment | Temperature: -20–60°C |
Main Features
- High Accuracy & Stability
- 128×128 LCD with Rotatable Display
- Mean, Max, Min & Std. Deviation Display
- Alarm Limit with Red Backlight
- Data Storage, Recall & Deletion
- Zero & Multi-Point Calibration
- USB PC Connectivity
- Multi-Language Support
- Supports 5 Measurement Groups
- Automatic Substrate Detection (F/N)
- Accurate Readings: Displays max, min, average, and standard deviation.
- Smart Detection: Auto-detects ferrous and non-ferrous substrates.
- Reliable Measurements: Ensures precision even with probe retraction.
- Effortless Operation: Rotatable LCD with user-friendly interface.
- Non-Destructive: Measures without damaging materials.
- Versatile Compatibility: Works with Fe and NFe metals.
- Data Management: Stores, recalls, and deletes up to 2000 readings.
- Calibration Support: Zero and multi-point calibration.
- Alarm System: Red backlight for user-defined limits.
- PC Connectivity: USB support for data transfer.
- Multi-Language Support: Supports various languages.
- Measurement Groups: Handles up to 5 groups
Industrial Applications
- Automotive
- Aerospace
- Construction
- Metal Processing
